Size Range: 2" to 24" (DN50 to DN600)
Standards: BS/ANSI/AWWA/DIN
Pressure Rating: PN10 / PN16 / PN25
Body & Bonnet: Ductile Iron
Sealing Wedge: Ductile Iron fully wrapped in heavy-duty EPDM rubber
Stem Material: Stainless Steel
Coating: Professional-grade Blue/Red Epoxy (FBE)
End Connections: Flanged end
Application Medium: Drinking water,sewage,seawater,irrigation,or other neutral liquid
Where to Use It
Municipal Water Mains: Perfect for underground distribution where burial depth is limited.
Industrial Cooling: Reliable isolation for process water in tight piping galleries.
Irrigation Control: Durable shutoff for pump stations and agricultural headers.
Building HVAC: Space-saving isolation for water risers and mechanical rooms.
FAQ
Why should I choose an NRS gate valve over an OS&Y model?
If you are burying the valve or installing it under a low ceiling, you need an NRS valve. Since the stem doesn't rise, you don't need to worry about the valve hitting a ceiling or needing a deep, expensive vault for underground access.
Does the flat-bottom design really prevent leaks?
Yes. Traditional gate valves have a "pocket" at the bottom where stones and silt collect, preventing the gate from closing fully. Our resilient seat design eliminates this pocket, so the wedge seals against a flat surface, and debris is simply washed away by the flow.
What kind of maintenance does this valve require?
Very little. Thanks to the FBE coating and the EPDM-wrapped wedge, the internal parts are shielded from the water. Regular cycling of the valve is usually all that's needed to keep the stem moving smoothly for years.
If you need a NRS Gate Valve that won't let you down, reach out to the Keylion VALVE team. We can provide bulk quotes, technical drawings, and help you pick the right specs for your next job.
