Fire Hose Rack
Fire Hose rack (Pin rack) is semi-automatic swinging component used to store fire hose and permit one man operation of complete unit. It has retention device prevents water flow until last fold of fire hose is removed from the rack.
Cold steel shelf and pins
Red enamel coating
1.5''/2.5''
Fire hose capacity
Available Size
| Size | Feature | Valve & nipple connection | Fire Hose Connection | Fire hose capacity |
| 1-1/2'' | Semi-auto swing | 1-1/2'' | Rack, 1-1/2″ | Up to 100' |
| 2-1/2'' | Semi-auto swing | 2-1/2'' | Rack, 1-1/2″ | Up to 100' |
| 1-1/2'' | Semi-auto swing | 1-1/2'' | Rack, 1-1/2″ | Up to 100' |
| 2-1/2'' | Semi-auto swing | 2-1/2'' | Rack, 1-1/2″ | Up to 100' |
Frequently Asked Questions
Q: Is the rack corrosion-resistant for outdoor or humid environments?
+
-
Yes. Our racks feature a heavy-duty steel construction finished with a premium electrostatic red powder coating or epoxy enamel. This provides superior resistance against rust, moisture, UV rays, and harsh industrial environments. For extreme conditions, stainless steel options are also available.
Q:Can this fire hose rack accommodate different sizes of hoses?
+
-
Yes. Standard commercial racks are highly versatile and typically accommodate either 1-1/2" (38mm) or 2-1/2" (65mm) inner diameter (ID) fire hoses, with storage capacities ranging from 50 feet to 100 feet (15 to 30 meters) depending on the model.
Q:What is the purpose of the "center-hump" or curved design on the rack?
+
-
The curved structure or hump is specifically designed to extend the lifespan of the hose. It reduces sharp bends and relieves physical stress on the folded ends of the hose, which prevents the inner rubber or polyurethane lining from cracking during long-term storage.
